Metal halide perovskites as a new generation of semiconductor optoelectronic
materials, have great potential for applications in solar cells, light-emitting diodes (LEDs), and
photodetectors. Typical perovskite photovoltaic devices are mainly based on polycrystalline
thin-films. However, the numerous grain boundaries and high defect density in polycrystalline
thin films hinder the improvement of device performance. Perovskite thin single-crystalline
materials, due to their superior optoelectrical properties such as lower defect density and
longer carrier diffusion length compared to polycrystalline thin films, have attracted great
attentions in solar cells, photodetectors, X-ray detectors, and lasers. This review systematically introduces the preparation techniques, optimization strategies (component engineering,
additive engineering, interface passivation) and device application progress of perovskite thin
single-crystalline materials. It focuses on the growth methods and performance regulation of
perovskite thin single-crystalline materials. Additionally, it discusses the development of perovskite thin single-crystalline materials as solar cells, photodetectors, X-ray detectors, and as
light-emitting devices. Subsequently, it introduces the patterning methods of perovskite thin
single-crystal, including inkjet printing and patterning template-induced arraying techniques,
as well as the challenges, and looks forward to the future development directions of perovskite
thin single-crystal devices.
